LIQUID RESIN PROPERTIES
R'CPOL 144M
| 1 |
Appearance |
Hazy |
| 2 |
Acid Value |
18-22 mg koh/gm |
| 3 |
Viscosity |
300-400 cps |
| 4 |
Solid Content |
58-62% |
| 5 |
Moisture |
0.15% max |
| 6 |
Density |
1.1-1.12 kg/L |
CURING CHARACTERISTICS
AT 30 °C [1.5% ΜΕΚΡ (50%) + 0.5% CO (3%)]
| 1 |
Geltime |
3-5 Minutes |
| 2 |
Time to Peak |
7-9 Minutes |
| 3 |
Peak Exotherm |
185-210 °C |
LIQUID RESIN PROPERTIES
R'C POL 117
| 1 |
Appearance |
Clear |
| 2 |
Acid Value |
15-19 mg koh/gm |
| 3 |
Viscosity |
300-400 cps |
| 4 |
Solid Content |
58-62% |
| 5 |
Moisture |
0.15% max |
| 6 |
Density |
1.1-1.12 kg/L |
CURING CHARACTERISTICS
AT 30 °C [1.5% ΜΕΚΡ (50%) + 0.5% CO (3%)]
| 1 |
Geltime |
5-7 Minutes |
| 2 |
Time to Peak |
7-9 Minutes |
| 3 |
Peak Exotherm |
170-200 °C |
