Lamination
Lamination grade unsaturated polyester resin (UPR) is specifically formulated for use in fiberglass reinforced plastic (FRP) lamination processes. This type of resin is designed to provide excellent wet-out properties, allowing it to thoroughly impregnate fiberglass mats or fabrics. Designed specifically for lamination applications, it offers unparalleled resistance to the light transmission and withstands various weather conditions at typical room temperatures. This resin formulation maintains a transparent appearance, ensuring clarity and longevity in its lamination application.
LIQUID RESIN PROPERTIES
R'C POL 405
| 1 | Appearance | Clear Transparent |
|---|---|---|
| 2 | Acid Value | 12-18 mg koh/gm |
| 3 | Viscosity | 270-330 cps |
| 4 | Solid Content | 58-62% |
| 5 | Moisture | 0.15% max |
| 6 | Density | 1.1-1.12 kg/L |
CURING CHARACTERISTICS
AT 30°C [1.5% ΜΕΚΡ (50%) + 0.5% CO (3%)]
| 1 | Geltime | 4-6 Minutes |
|---|---|---|
| 2 | Time to Peak | 6-8 Minutes |
| 3 | Peak Exotherm | 190-210 °C |
LIQUID RESIN PROPERTIES
R'C POL 405P
| 1 | Appearance | Clear Transparent |
|---|---|---|
| 2 | Acid Value | 17-23 mg koh/gm |
| 3 | Viscosity | 270-330 cps |
| 4 | Solid Content | 58-62% |
| 5 | Moisture | 0.15% max |
| 6 | Density | 1.1-1.12 kg/L |
CURING CHARACTERISTICS
AT 30°C [1.5% ΜΕΚΡ (50%) + 0.5% CO (3%)]
| 1 | Geltime | 12-18 Minutes |
|---|---|---|
| 2 | Time to Peak | 12-18 Minutes |
| 3 | Peak Exotherm | 170-200 °C |
LIQUID RESIN PROPERTIES
R'C POL 405S
| 1 | Appearance | Clear Transparent |
|---|---|---|
| 2 | Acid Value | 19-25 mg koh/gm |
| 3 | Viscosity | 270-330 cps |
| 4 | Solid Content | 58-62% |
| 5 | Moisture | 0.15% max |
| 6 | Density | 1.1-1.12 kg/L |
CURING CHARACTERISTICS
AT 30°C [1.5% ΜΕΚΡ (50%) + 0.5% CO (3%)]
| 1 | Geltime | 4-6 Minutes |
|---|---|---|
| 2 | Time to Peak | 7-9 Minutes |
| 3 | Peak Exotherm | 170-200 °C |
