Grating

Grating grade resin refers to specialized resins used in the production of plastic gratings. These gratings are lightweight, durable, and resistant to corrosion, making them ideal for various industries including construction, marine, and chemical processing. The resin offers qualities such as high strength-to-weight ratio, corrosion resistance against chemicals and UV exposure, non-conductivity, and low maintenance requirements. These resins are chosen for their robust mechanical properties and ability to withstand harsh environments effectively

LIQUID RESIN PROPERTIES

R'C POL 126
1 Appearance Opaque
2 Acid Value 13-17 mg koh/gm
3 Viscosity 300-400 cps
4 Solid Content 58-62%
5 Moisture 0.15% max
6 Density 1.1-1.12 kg/L

CURING CHARACTERISTICS

AT 30°C [1.5% ΜΕΚΡ (50%) + 0.5% CO (3%)]
1 Geltime 5-7 Minutes
2 Time to Peak 9-13 Minutes
3 Peak Exotherm 170-200 °C
